Evapco Dry Cooling — UK & Ireland

Industrial-scale dry cooling — no water, no compromise.

From the field-erected eco-Air TITAN — built for power generation, data centres and large-scale industrial heat rejection — to industrial air cooled condensers for water-scarce and plume-sensitive sites. ) (cps supplies, installs, maintains and services the full Evapco Dry Cooling range for the UK and Ireland.

2 product lines
Zero water consumption
Field-erected to factory units
Partnerships

Two dry cooling technologies, one UK & Ireland route.

) (cps represents Evapco Dry Cooling in the UK and Ireland — Evapco Dry Cooling specialises in air-cooled heat exchangers and air cooled condensers for power generation, carbon capture, heavy industrial, data centres and large-scale process cooling. The range runs from the field-erected eco-Air TITAN for very large heat rejection duty, through to factory-assembled air cooled condensers for industrial refrigeration and process sites.

Both product lines share the same core engineering principle: zero water consumption — no water treatment, no plume, no cooling tower risk, lower maintenance overhead than any evaporative alternative.

/ Partnership 01
Evapco Dry Cooling

Specialists in field-erected air-cooled heat exchangers for large-scale heat rejection — power generation, carbon capture, data centres and heavy industrial. The eco-Air TITAN uses proven finned tube bundle technology in a large-fan, field-erected structure to deliver high capacity in a compact plot area.

/ Partnership 02
Evapco Europe

Factory-assembled air cooled condensers for industrial refrigeration, process cooling and water-scarce sites. Zero water consumption — no treatment chemistry, no plume, no cooling tower Legionella risk — and lower routine maintenance than any evaporative alternative.

Water use
Zero

Both product lines are fully dry — no water treatment, no cooling tower risk, no plume.

TITAN fan diameter
Up to 36 ft

Large high-efficiency fans reduce auxiliary power and cut noise footprint versus conventional fin fan coolers.

eco-Air installations
1,000+

The eco-Air Series finned tube bundle technology at the heart of the TITAN has been proven across over 1,000 installations since 2017.

Maintenance
Lower than wet

No water treatment chemistry, no fill replacement, no drift eliminators — simpler, lower-cost routine inspection.

The dry cooling range

02  product lines
01 / Industrial scale
Evapco Dry Cooling

eco-Air TITAN

The eco-Air TITAN is EVAPCO's field-erected air-cooled heat exchanger for large-scale heat rejection duty — designed for power generation, carbon capture, data centres, heavy industrial and battery plants. It takes EVAPCO's proven eco-Air Series finned tube bundles (over 1,000 installations since 2017) and integrates them into a large-fan, field-erected structure that leverages the efficiencies of EVAPCO's Advanced Technology ACC. V-configured fin/tube bundles are elevated to permit optimal airflow, delivering substantial cooling capacity in a compact plot area. High-efficiency fans up to 36 ft in diameter reduce auxiliary power consumption and noise footprint. Manufactured using modularised standard components for ease of transportation and field erection. Type 304L stainless steel tubing with aluminium fins as standard — ASME B31.5 compliant.

Ec0-air titan catalogue
02 / Industrial
Evapco Dry Cooling

Air Cooled Condensers

Industrial-scale forced-air condensers delivering zero water consumption and lower maintenance than any evaporative alternative — the right choice for water-scarce sites, or wherever plume abatement is critical to planning consent or environmental permitting. Dry operation eliminates water treatment chemistry, drift eliminators and cooling tower risk. Typical applications include industrial refrigeration, process cooling, power generation on water-restricted sites and urban or residential-adjacent plant where a visible cooling plume is unacceptable.

View Air Cooled Condensers →
/ Thermal performance
100%

No water. No plume. No compromise.

Both dry cooling product lines share the same fundamental advantage over evaporative plant: zero water consumption. No water treatment programme, no Legionella risk management plan for the tower, no visible plume — and significantly lower maintenance overhead year-round. For sites where water scarcity, environmental permitting or planning sensitivity make evaporative cooling impractical, dry cooling is not a compromise: it's the right engineering answer.

Materials engineering

Built for the duty, the fluid and the environment.

01

Copper tube, aluminium fin

Standard construction

The default for general dry cooling duty — efficient heat transfer, established lifecycle, suitable for most water and glycol process applications including the eco-Air TITAN and standard ACC builds.

02

All stainless steel

Corrosion-resistant

For aggressive process fluids, coastal or offshore environments, or food-grade duty where galvanic corrosion, chemistry or hygiene requirements rule out conventional copper-aluminium construction.

03

Micro-bore all aluminium

Ammonia & space-saving

Space-saving construction with the smallest plot-area footprint — and the ideal solution for ammonia condensing, avoiding the copper incompatibility of conventional builds. Available on air cooled condensers.

Full lifecycle

Beyond supply: install, maintain, service, repair.

01

Supply

Selection support and direct supply of eco-Air TITAN and air cooled condensers, sized and specified by our engineers for your duty and site conditions.

02

Install

Approved Evapco installer for both product lines — mechanical and structural installation with full commissioning and performance verification.

03

Maintain

Planned preventive maintenance contracts — significantly lighter than wet equivalents but still required.

04

Service

Reactive service, troubleshooting and component replacement on all dry cooling plant.

05

Repair

Coil repair and replacement, fan and drive overhaul, structural and control refurbishment.

Sectors served

Where water-saving matters
01 Data centres
02 Industrial refrigeration
03 Ammonia & CO₂ systems
04 Process industry
05 Building services & HVAC
06 Food production
07 Offshore & marine
08 Power generation
09 Pharmaceutical

Also see

01 — Cooling Towers

Evapco wet range

If full evaporative cooling is acceptable, the Evapco wet range delivers higher capacity per footprint than dry equivalents — cooling towers, closed circuit coolers and evaporative condensers.

View Evapco wet →
02 — Thermal Upgrades

Hybrid conversion

For existing wet plant, hybrid conversion combines dry and adiabatic sections to cut water use and plume without full equipment replacement.

View upgrades →

Cutting water from cooling?

Call +44 (0)1535 273 580 or send the duty & fluid spec — we'll size the right dry or adiabatic solution.

Request Selection Call Now
